Pilot Revision–Airlaw

By Carl Fairhurst on  November 22, 2018 12:18

Image may contain: 1 person, indoorOn the 19th Novemer, Richard Butterworth gave a review of the airlaw part of the pilot exam, along with additional hints and tips and some exercises to help in everyday flying which are not on the exam.



The you tube video of a similar session presented by Gordon Bishop to the Derbyshire Soaring Club can be found on YouTube at https://www.youtube.com/watch?v=lxmMRsRGuGk

IMG_3738

Coaching Exercise - Navigation and Instruments

By Phil Colbert on  August 6, 2017 21:05

For those taking part in the coaching exercise on navigating with your instruments - make sure you read  and study the manual for your software/instrument. Download the two waypoint files, unzip them and install them in the correct place on your instrument. Check that you can access them. On the day you will need to assemble a task using selected waypoints, edit the size of the waypoint circles, then complete the task.

PSC Training Waypoints

Kobo instrument night with Phil Colbert

By Carl Fairhurst on  September 2, 2015 19:04

Wednesday, September 23 at 7:30pm

The Boaryard Inn. Bolton Road. Riley Green. PR5 0SP.

Phil Colbert will host a Pennine Soaring Club instrument night focusing on the use of a Kobo tablet and the use of LK 8000 and XC Soar. Points to be covered : GPS connection , sounds/warnings , screen profiles , maps , waypoints and tasks using XC Planner . Illustrations by way of computer projection so we can all see the instrument manipulation.
Phil Colbert will welcome input from members already using Kobo. Please bring your Kobo to the instrument evening.

Getting waypoints into your GPS

By Simon Blake on  October 7, 2014 20:58

How to get waypoints into your GPS the easy way.
If you've got the electronic version of the Defined Tasks Coaching guide, you'll also have a GPX file of waypoints. Getting these waypoints into your GPS should be fairly straightforward, if you've got one of the popular units supported by GPSDump.
If you haven't already got GPSDump, get it now from here.

The first thing you need to do is establish communication with your device. If it's a Flytec or a Brauniger, make sure it's switched OFF, then plug it into the USB port. If it's a Garmin, make sure it's switched ON, then plug it into the USB port. Don't know about any others, but you should be able to work it out. In extreme circumstances, you might like to check the manual.
Once it's plugged in physically, it's time to see if GPSDump can see it.
Click the "Logs" menu, and select an option that mentions your instrument. If you're lucky, it will start reading logs straight away. If you're not, it will say "Connecting to GPS" and start counting down. This means it can't see your instrument. If it's plugged in and properly connected physcially, this just means it's looking in the wrong place, i.e. the wrong COM port.
To change the COM port, click the "Misc" menu, and select the top option, "Set COM port". A drop down menu will present you with some options. Pick one, and repeat the process of trying to read logs. Eventually, you should get a working connection.
Now you have a working connection with your instrument, it's time to get all 78 waypoints into your instrument in just a few seconds, with no typing in.
First, load the waypoints into GPSDump. Click "File", then "Open wpts.". Navigate to wherever you've put "Paragliding waypoints database full.gpx", and click on it. You will see the list of 78 waypoints. If you don't have a copy of the GPX file, it's available from simonpblake@hotmail.com
Now you need to send them to your instrument. Click "Edit", then "Select All". This will select all 78 waypoints.  (If you want, you can just select a few, just the Grid Challenge waypoints, say. For now, though, select all of them.) Now click "Wpts", then "Send to..." and whichever option mentions your instrument. It should take just a few seconds to confirm that all the waypoints have been sent.
If you examine your instrument, you should now find all the waypoints are present. You may need to set the correct radii - most are the standard 400m, but some are smaller. Check the Defined Task Guide for details.
You can now set up routes using those waypoints - consult your instrument manual for details of how to set up routes. For details of what the routes are, see the Defined Task Coaching guide.
A summary of the routes is given below:
